德国Coax阀有着45年的研发历史，适用于各种对产品质量要求非常高而环境非常恶劣的工业场合。Coax阀具有20000多不同型号的阀，能函盖所有的工业应用场合，是企业控制、调节、监控工业介质的坚实伙伴。
德国COAX以生产同轴阀著称，凭借丰富的经验，可靠而经过严格测试的材质，过硬的质量管理，已代表了工程、制造以及创新工艺方案的技术。CO-AX已将同轴阀发展成为用于控制真空气态、液态、凝胶状、有颗粒、高污染和强腐蚀性介质的可靠产品。COAX同轴阀的设计与普通阀门相比，具有在高流量工况下控制高压的特点。并能提供二位二通或二位三通的形式，有螺纹或法兰连接方式。阀门可通过直动电磁阀或外部驱动。COAX阀门用于控制、调节和止回,适合各种介质，包括从低到高粘性的，从润滑到有颗粒的，从化学性能中性到强腐蚀的，COAX阀门都能应对自如，而且保证质量不变，标准。COAX核心产品有XX COAX电磁阀、XXCOAX电动调节阀、XX-COAX气动调节阀、XX COAX自力式调节阀、XXCOAX温度调节阀、COAX压力调节阀、COAX电动球阀、COAX气动球阀、COAX电动蝶阀、COAX气动蝶阀及真空泵。

2/2 way coaxial direct acting
3/2 way coaxial direct acting
2/2 way coaxial externally controlled
3/2 way coaxial externally controlled
certificated valves
cartridge valves
lateral valves
high pressure valves coaxial
high pressure valves lateral
modules and manifolds
pressure control valves
flow control valves
special valves
function NC - normally closed, NO - normally open
body materials aluminium, brass, galvanized steel, nickel plated brass, nickel plated steel, without non-ferrous metals, stainless steel
seal materials NBR, PTFE, FPM, CR, EPDM, special seal materials
media gaseous, liquid, gelatinous, highly viscous, pasty, contaminated, aggressive
actuation DC direct current coil
AC direct current coil with integrated / separated rectifier
nominal voltage DC 24 V / AC 110 V / AC 230 V
electrical connection plug acc. DIN EN 175301-803, form A, LED
insulation rating H 180°C
enclosure protection IP 65
energized duty rating ED    (16 bar max.)
vacuum leak rate 10-6 mbar
options special threads, special flanges, function NO, damping, limit switches, manual override, approvals, mounting, special voltage, plug M 12 x 1, terminal box
