宝德BURKERT电磁阀类型说明

0330阀门是一种直接作用，介质分离的枢轴式电枢阀。它有3/2和2/2版本。作为3/2版本，它可以用作分配器或混合阀。根据应用，可以使用各种隔膜材料组合和操作方法。标准黄铜外壳满足所有欧洲饮用水要求。不锈钢（316L），PVDF和聚丙烯外壳版本*善了产品。电磁线圈采用耐化学腐蚀的环氧树脂模制而成。 0330配有手动控制装置，用于调试和测试。为了降低能量需求，所有线圈都可以通过电子功率降低或作为脉冲版本来提供。可以用位置反馈将开关状态指示为二进制或NAMUR信号。与符合DIN EN 17301-803 A型的插头组合使用时，阀门符合防护等级IP65 / 67  - 与不锈钢或塑料外壳NEMA 4X组合使用。

直动式介质分离阀，直径大DN 5

免维护的枢轴电枢技术

防振，块螺纹线圈系统

适用于腐蚀性碱性和酸性溶液

服务友好，强大的手动操作

如需选择正确的产品，请参阅技术数据，图像和注释，以便根据数据表正确使用。

BURKERT电磁阀00136350上海区域授权***

Type Description

The 0330 valve is a direct-acting, media separated pivoted armature valve. It is available in 3/2- and 2/2-way versions. As a 3/2-way version, it can be used as a distributor or mixing valve. Various diaphragm material combinations and methods of operation are available depending on the application. The standard brass housing satisfies all European drinking water requirements. Stainless steel (316L), PVDF, and polypropylene housing versions complete the offering. The solenoid coils are moulded with a chemically resistant epoxy. The 0330 is equipped with manual override for commissioning and testing. For reduced energy requirements all coils can be delivered with electronic power reduction or as an impulse version. The switching status can be indicated with position feedback as a binary or NAMUR signal. In combination with a plug in accordance with DIN EN 17301-803 Form A, the valves satisfy protection class IP65/67 – in combination with a stainless steel or plastic housing NEMA 4X.

• Direct-acting, media separated valve with diameter of up to DN 5
• Maintenance-free pivoted armature technology
• Vibration-proof, block screwed coil system
• Suitable for aggressive alkaline and acidic solutions
• Service-friendly, robust manual operation
